Note: our company can provide all types of high-voltage motor configuration, soft start variable frequency start, etc.
（水冷式） 型 號 | 容積流量壓力 (M3/min)(Mpa) | 電動機 | 氣體含油量 (PPM) | 外形尺寸 | 接口管徑 （inch） | 重量（kg） | 噪音 db(A) | 冷卻水量 | 進出口水壓差(Mpa) | 水管外接管徑(inch) | ||||||
功率 （KW） | 電壓防護等級 | 長 (mm) | 寬 (mm) | 高 (mm) | ||||||||||||
FHOGD-PM45-II | 4.1-10.2/0.7 | 4.0-9.2/0.8 | 3.6-7.3/1.0 | 2.8-6.4/1.25 | 45 | 380V/ 50HZ IP54 | ≤2 | 1900 | 1300 | 1600 | 1-1/2" | 1630 | 65±2 | 2 | ≥0.18 | G1" |
FHOGD-PM55-II | 5.2-13.1/0.7 | 4.8-12.2/0.8 | 4.0-10.0/1.0 | 3.6-8.7/1.25 | 55 | 2100 | 1300 | 1600 | 2" | 1800 | 65±2 | 2.4 | ||||
FHOGD-PM75-II | 6.2-15.6/0.7 | 6.0-15.2/0.8 | 5.2-13.5/1.0 | 4.0-11.2/1.25 | 75 | 2200 | 1450 | 1600 | 2" | 2040 | 69±2 | 3.2 | ||||
FHOGD-PM90-II | 8.2-21.0/0.7 | 7.8-19.5/0.8 | 6.4-16.0/1.0 | 5.5-15.2/1.25 | 90 | 2500 | 1600 | 1700 | DN65 | 2780 | 72±2 | 4.2 | G1-1/2" | |||
FHOGD-PM110-II | 9.6-24.0/0.7 | 9.2-23.0/0.8 | 7.6-20.0/1.0 | 6.4-16.0/1.25 | 110 | 2500 | 1600 | 1700 | DN65 | 2920 | 75±2 | 5 | ||||
FHOGD-PM132-II | 12.0-30.0/0.7 | 10.8-27.0/0.8 | 9.2-23.0/1.0 | 7.8-19.5/1.25 | 132 | 2800 | 1800 | 1850 | DN80 | 3600 | 75±2 | 6 | ||||
FHOGD-PM160-II | 13.6-34.0/0.7 | 13.2-33.2/0.8 | 11.0-27.5/1.0 | 9.0-22.5/1.25 | 160 | 2800 | 1800 | 1850 | DN80 | 3600 | 76±2 | 7 | ||||
FHOGD-PM185-II | 16.0-40.0/0.7 | 15.6-39.0/0.8 | 13.0-32.5/1.0 | 11.0-27.5/1.25 | 185 | 3000 | 2100 | 2150 | DN100 | 4050 | 76±2 | 9 | G2" | |||
FHOGD-PM200-II | 17.0-42.5/0.7 | 16.6-41.5/0.8 | 14.8-37.0/1.0 | 12.8-32.9/1.25 | 200 | 3000 | 2100 | 2150 | DN100 | 4200 | 76±2 | 9 | ||||
FHOGD-PM220-II | 20.0-53.0/0.7 | 18.4-47.1/0.8 | 15.6-43.0/1.0 | 13.2-37.8/1.25 | 220 | 3200 | 2200 | 2200 | DN100 | 4800 | 78±2 | 15.2 | ||||
FHOGD-PM250-II | 21.6-54.0/0.7 | 20.4-51.2/0.8 | 16.4-41.0/1.0 | 15.6-39.0/1.25 | 250 | 6KV~ 10KV IP23 | 3500 | 2200 | 2200 | DN125 | 5600 | 78±2 | 15.2 | |||
FHOGD-PM280-II | 24.0-60.0/0.7 | 22.8-57.0/0.8 | 19.8-49.5/1.0 | 17.2-43.0/1.25 | 280 | 3800 | 2200 | 2200 | DN125 | 5800 | 78±2 | 16 | DN65 | |||
FHOGD-PM315-II | 26.8-67.0/0.7 | 24.8-62.0/0.8 | 22.4-56.0/1.0 | 20.4-51.0/1.25 | 315 | 3900 | 2200 | 2200 | DN125 | 6200 | 78±2 | 16 | ||||
FHOGD-PM355-II | 29.2-73.0/0.7 | 27.6-69.0/0.8 | 24.4-61.0/1.0 | 21.6-54.0/1.25 | 355 | 4200 | 2200 | 2200 | DN125 | 6200 | 82±2 | 16 | ||||
